RSK-TBG 8 ZT excelsum torsional rigorem ac nulla backlash diaphragma copulatio apta test scamnum

RSK-TBG 8 ZT excelsum torsional rigorem ac nulla backlash diaphragma copulatio apta test scamnum

Contact Us
  • Specification
  • Describe
Specification

Exemplar: RSK-TBG 8102F 8102 8132 8178 8210 8252
Rated Torque TKN N.m 190 300 1100 3500 5800 10000
Apicem Torque TKS N.m 285 450 1650 5250 8700 14250
Diameter exterior D mm 102 102 132 178 210 252
Foramen Diameter d mm 25-45H5 25-45H5 45-70H5 50-85H5 60-100H5 70-120H5
Maximum Volo Nmax min−1 30000 30000 25000 20000 16000 13000
Axial cinguli Ka mm 0.2 0.2 0.3 0.4 0.4 0.5
Radialis cinguli Sleeve1 Kr mm 0.06 0.06 0.08 0.08 0.11 0.13
Angularis cinguli ° 0.3 0.2 0.2 0.16 0.16 0.16
Angulus Spring rigoris Nm/rad 229 285 1850 6980 11250 18580
Diaphragma pone Crassitudo S mm 7.1 4.6 6.8 11.2 12 14

Nota: Pro velocitatibus super 5000rpm, cinguli ad maximum 30% regenda.







Related Product
Societas
Jiangsu Rokang Heavy Industry Technology Co., Ltd.
Jiangsu Rokang gravis Industry Technologia Co, Ltd certa bona plus quam LXXX decies Yuan, et habet quadrigis professionales talenta in mechanico consilio, praecisio vestibulum, calor curatio, glutino, etc; Societas unum finem habet integram copiam processus facilitatum et seriem qualitatis inspectionis systematum ut mensurae, physicae et chemicae, et probatio dynamicae, et capacitatem processus mechanicam comprehendens habet. Multos annos sodalitas commissa est investigationi et evolutioni et fabricationi globulorum cavearum, typus constantis velocitatis universae commissurae, genus commissurae crucis universalis, et iuncturas calces tympani. Arcam industriam-universitatis-investigationis cooperationem cum Institutis militaribus et localibus inquisitionis scientificae ac potentiae Engineering Department of PLA Naval Academiae peregit, et in agros praecisiones, sarcinas magnas et celeritatem continenter dilatavit. Producta in notam notam externam feliciter restituerunt cum praestantia observantia, et processus technologiae ad gradum internationalem provectum pervenit. Plurimum adhibitum est in levatione et translatione, machinatione metallurgica, machinis metallicis, machinis machinariis, machinis fodiendis, machinis petrochemicis, machinis textilibus, navibus militaribus, vehiculis armatis, machinationibus ferriviariis, vehiculis aliisque campis specialibus. Producti qualitas et servitia a pluribus utentibus agnita et laudata sunt, et in Europam, Americam, Russiam, Orientem Medium, Indiam et alias regiones et regiones exportantur. As ChinaSuppliers of RSK-TBG 8 ZT excelsum torsional rigorem ac nulla backlash diaphragma copulatio apta test scamnum, Rokang offer Wholesale RSK-TBG 8 ZT excelsum torsional rigorem ac nulla backlash diaphragma copulatio apta test scamnum. The company has always adhered to the business purpose of "quality first, honest management, and customer first". We are willing to work with you with excellent products, preferential prices and thoughtful services to create a brilliant career!
